PET PETG Transparent sheet extrusion line
PET Thermoforming sheet Extruding machine
Single and multi-layer PET sheet extrusion line
PET PETG PETC APET RPET shee Production Line
1. PET Sheet Applacations:
PET sheet is mainly used for food, medical, electric, make up, printing, container ,3D film etc.
2. PET PETG Sheet Product features:
| sheet types | Single layer or multilayer. |
| layer structure | A
A+B
A+B+A |
| Processing material | PET virgin pellets(APET or PETG) plus flakes; or 100% flakes |
| Net sheet width | 600-1500mm (or as per customer's requirements) |
| Thicknes range | 0.15-1.5mm |
| Capacity | 350-500kg/h |
| Application | thermoforming ( cup, bowel, etc.), Packaging, decoration, stationery, printing,
fruit tray, electric packaging, etc. |
| Machine advance | the sepecial design as per the material characteristics and the sheet production process, which fully meets the customers' high quality sheet required. |
| Production plan | Single Screw extrsion line or Parallel twin screw extrusion line. |
3. PET Sheet Extrusion Line Consists:
| PET PETG PETC APET RPET Sheets Line Consists: |
| 1. | Single Screw Extruder or Parallel twin screw extruder | 1 set or 2 sets or 3 sets |
| 2. | Duplex hydraulic screen changer | 1 set |
| 3 | Melt pump | 1 set |
| 4. | Extrusion Die Head T-die Head | 1 set |
| 5 | Three Roller Calendar,45 degree with temperature controller for rollers | 1 set |
| 6 | Bracket and Haul-off machine | 1 set |
| 7 | winding machine | 1 set |
| 8 | Electric control system | 1 set |
| 9 | Crystalline | 1 set |
4. PET Sheet Extrusion Line Main Technical Specification:
| SPECIFICATIONS FOR Pet/PETG/Petc Precision Sheet Making Machine |
| Model | SJ120-SJ1200 high exfficient | XSP-75/40-GF1000 Non crystalline |
| Extruder Model | SJ120/35 single screw | XSP75/40 parallel double screw |
| Main motor power | 110KW | 132KW |
| Products thickness | 0.15-2.0mm | 0.15-2.0mm |
| Capacity | 500kg/h | 600kg/h |
